- Ready to use The R1 Basic runs from the Unitree Explore app, the supplied remote and voice, with no programming needed.
- 26 joints in a 29 kg body Six joints in each leg, five in each arm and two each in the waist and head move a humanoid about 1.23 m tall that folds to 690 × 450 × 300 mm.
- Binocular depth camera The head camera covers 146° × 124° and gives RGB at 1280 × 720 and depth at 544 × 448, with a 10 TOPS visual computing module and an 8-core CPU on board.
- Voice and image interaction A 4-microphone array, stereo 3 W speakers and a large multimodal model handle conversation when the robot is online; it wakes to "Hello Robot".
- Running, dancing and gestures Running mode at low or high speed, dance modes such as Kung Fu and Jeet Kune Do and gestures such as handshake, wave and clap are built into the remote.
- Quick-release battery A 6000 mAh smart battery gives about 1 hour of use and charges in about 1.5 hours outside the robot.
- 8-month manufacturer warranty The R1 Basic carries Unitree's 8-month warranty; SDK access and a 12-month warranty come with the R1 EDU.
Description
The Unitree R1 Basic is the ready-to-use edition of Unitree's R1, the edition Unitree sells simply as "R1": a lightweight bipedal humanoid about 1.23 m tall and 29 kg with its battery, with 26 joint motors (6 in each leg, 5 in each arm, 2 in the waist and 2 in the head), a binocular depth camera and voice and image interaction.
You run it from the Unitree Explore app on iOS or Android, the supplied remote and your voice. The remote holds running mode at low or high speed, dance modes such as Kung Fu and Jeet Kune Do and gestures such as handshake, wave and clap; the voice assistant wakes to "Hello Robot" and, online, answers through a large multimodal model. It stands up from lying flat or starts on the supplied stand, and receives smart OTA upgrades.
The R1 Basic has no secondary development: no SDK access, no computing backpack and no dexterous-hand option, and its hands are fixed. It suits shows, demonstrations and voice and image interaction where the robot is used as it comes. Unitree specifies 0–40 °C on flat ground; the R1 is neither waterproof nor dustproof.
To program the R1, choose an R1 EDU on the same body: the R1 EDU Standard (U1) and R1 EDU Smart (U2) add unitree_sdk2, ROS 2 and an NVIDIA Jetson Orin backpack (40 or 100 TOPS), and Pro A, Pro B, Pro C and Pro D add two dexterous hands. The R1 Basic carries an 8-month manufacturer warranty, every R1 EDU 12 months.
Key Capabilities
- Body: About 1.23 m and 29 kg, 26 joint motors, folding to 690 × 450 × 300 mm.
- Perception: Binocular depth camera (146° × 124°), 8-core CPU and 10 TOPS visual computing module.
- Interaction: 4-microphone array, stereo 3 W speakers, voice and image AI through a large multimodal model.
- Control: Unitree Explore app, remote with emergency stop, voice; running, dance and gesture modes.
- Power: 6000 mAh quick-release smart battery: about 1 h of use, about 1.5 h to charge.
- Warranty: 8 months from Unitree; no secondary development on this edition.
Buying through Robotix Market
This unit is sourced new through established distribution channels and ships worldwide with the manufacturer warranty. Technical support is coordinated with the manufacturer's own service network. Deployment scope, configuration, and commissioning responsibilities are agreed as part of the quotation — on-site installation is not included in the product price.
Official Product Videos
Features
Specs
| Brand | Unitree Robotics |
|---|---|
| Model | R1 Basic (Unitree name: R1) |
| Robot type | Bipedal humanoid robot |
| Size, standing | 1230 × 357 × 190 mm (height × width × thickness) |
| Size, folded | 690 × 450 × 300 mm |
| Weight | About 29 kg with battery |
| Colours | White or red; creative stickers to change the look |
| Body joints | 26 joint motors: 6 per leg, 5 per arm, 2 in the waist, 2 in the head |
| Total degrees of freedom | 26 |
| Leg and arm length | Calf + thigh 600 mm; forearm + upper arm 420 mm |
| Range of motion | Knee −10° to +139°; hip yaw ±157°, pitch −168° to +146°, roll −60° to +100°; waist yaw ±150°, roll ±30°; head yaw ±115°, pitch ±36° |
| Arm payload | About 2 kg per arm, varies greatly with arm posture |
| Drive | Low-inertia, high-speed inner-rotor PMSM joint motors; crossed roller and ball bearings; dual + single encoders; hollow internal wiring; local air cooling |
| Hands | Fixed hands, not actuated; no dexterous-hand option |
| Camera | Binocular depth camera in the head, 146° × 124° field of view; RGB 1280 × 720 at 30 Hz, depth 544 × 448 at 10 Hz |
| Computing | 8-core high-performance CPU + 10 TOPS visual computing module |
| Computing backpack | None; the computing backpack comes with the R1 EDU |
| Audio | 4-microphone array; stereo speakers, 3 W × 2 |
| Voice and image AI | Voice and image interaction through a large multimodal model when online; wake phrase "Hello Robot" or press-to-talk |
| Status light | 256-colour RGB chest light showing the robot's state |
| Wireless | Wi-Fi 6, Bluetooth 5.2 |
| Top panel | XT30 power outputs 24 V / 3 A and 36 V / 5 A; RJ45 gigabit Ethernet; stand-up / lie-down button |
| Battery | Quick-release smart battery, 6000 mAh |
| Run time | About 1 h per battery (less with fast walking, load or uneven ground) |
| Charger | 100–240 V input; 38 V, 3 A, 114 W output; about 1.5 h per charge, battery charged outside the robot |
| Remote control | Hard emergency-stop button and soft stop (L2 + B); 780 mAh, about 5 h; more than 100 m in an open environment |
| Control and updates | Unitree Explore app (iOS, Android), remote control and voice; smart OTA upgrades |
| Built-in actions | Running mode (low or high speed); dance modes including Kung Fu, Jeet Kune Do and Twist; gestures such as handshake, wave and clap |
| Secondary development | Not supported; the R1 EDU supports secondary development |
| Operating environment | 0–40 °C on flat ground; not waterproof, not dustproof |
| Warranty | 8 months |
| In the box | The robot in a hard transport case, a quick-release R1 smart battery, the charger and charging cable, a remote control with emergency stop, a stand set (base, support rod, bracket, quick-release clamp, wave washer and protective foam), a calibration steel shaft, body stickers and the user manual. Full packing list confirmed with your quotation |
Industries
Product Brochure
Unitree Robotics R1 Basic – Product Brochure
The Robotix Market brochure with every capability and the full technical specification — to save, print or forward.
Download Brochure (PDF)Frequently Asked Questions
The Unitree Robotics R1 Basic is priced at Rs. 980,300 in your market. For volume or project orders, contact us for a business quote.
They share the body, camera, computing, audio and battery. The R1 EDU adds secondary development (unitree_sdk2, DDS, ROS 2), a computing backpack with an NVIDIA Jetson Orin module, a dexterous-hand expansion module and a 12-month warranty. The R1 EDU Standard (U1) and R1 EDU Smart (U2) have 40 or 100 TOPS and no hands; Pro A and Pro B add two Unitree Dex3-1 hands, Pro C and Pro D two BrainCo Revo 2 hands. The R1 Basic has fixed hands and an 8-month warranty.
No. Unitree supports secondary development only on the R1 EDU, so the R1 Basic has no SDK access and no computing backpack. It runs from the Unitree Explore app, the remote and voice, with its built-in running, dance and gesture modes, and receives smart OTA upgrades. For your own software, choose an R1 EDU such as the R1 EDU Standard (U1).
Unitree's R1 unboxing film shows the robot in a hard transport case, a quick-release R1 smart battery, the charger and charging cable, a remote control with emergency stop, a stand set (base, support rod, bracket, quick-release clamp, wave washer and protective foam), a calibration steel shaft, body stickers and the user manual. Unitree publishes no written packing list per edition, so we confirm the full list for your configuration with your quotation.
About 1 hour per 6000 mAh quick-release smart battery, less with fast walking, vigorous posture changes, a load or uneven ground. The battery charges outside the robot in about 1.5 hours on the supplied charger (38 V, 3 A, 114 W); only Unitree's charger may charge it.
Unitree specifies 0–40 °C in good weather on flat ground. The R1 is neither waterproof nor dustproof; keep it at least 2 m from obstacles and crowds and operate it with care. It is not a toy and not intended for persons under 18.
The R1 Basic carries Unitree's 8-month manufacturer warranty; every R1 EDU carries 12 months. It is sourced new through established distribution channels and ships worldwide, and technical support is coordinated with the manufacturer's service network. Unitree publishes the R1 user manual, the battery-and-charger and remote-control manuals and tutorial films from unboxing onwards.
