- Single-Operator Mechanised Spraying Designed for one-person operation, reducing labour requirements compared to manual nozzle teams while maintaining consistent shotcrete placement quality.
- Operator Standoff Safety The machine positions behind the spraying arm during operation, keeping the operator more than 1 metre from the active spray surface and away from rebound and dust exposure.
- Small Turning Radius for Confined Spaces Compact chassis geometry with a tight turning radius allows effective manoeuvrability in narrow mine roadways and tunnels where space is severely constrained.
- Wide Spraying Range The articulating spraying arm geometry provides broad coverage across the working face, supporting efficient application on curved and irregular underground surfaces.
- High Load Capacity Rated load capacity of at least 4,000 kg supports the weight of spraying equipment, material supply lines, and associated tooling required for sustained shotcrete operations.
Description
The Topsky LT-CPF-60LY is a compact, tracked mobile spraying platform engineered for mechanized shotcrete (sprayed concrete) operations in underground mine roadways and tunnels. Designed for single-operator use, the system positions the operator safely behind the spraying arm with a standoff distance of more than 1 metre from the active spray face, significantly reducing exposure to rebound, dust, and unsupported ground conditions that define confined underground environments. Its small turning radius enables effective manoeuvrability in restricted headings where conventional equipment cannot easily reposition, while the wide spraying range of the articulating arm extends coverage across irregular or curved surfaces without requiring repeated machine relocation.
Built for shift-based underground operations, the LT-CPF-60LY carries a load capacity of at least 4,000 kg and is rated for up to 4 hours of continuous endurance per cycle, making it practical for structured ground-support workflows. A maximum travel speed of 1.5 m/s reflects the controlled, stability-first movement expected of underground construction machines. By reducing the manual labour requirements of shotcrete placement and keeping personnel further from the spray zone, the LT-CPF-60LY addresses the key industry drivers of workforce efficiency and site safety in mining and tunnel construction.
Features
Specs
| Brand | Topsky |
|---|---|
| Model | LT-CPF-60LY |
| Dimensions (L×W×H) | 4000 mm × 1800 mm × 2000 mm |
| Weight | ≤ 4,000 kg |
| Load Capacity | ≥ 4,000 kg |
| Maximum Speed | 1.5 m/s |
| Endurance | 4 hours |
| Operators Required | 1 (single-operator design) |
| Spray Surface Standoff Distance | > 1 m |
| Origin | China |
Industries
Frequently Asked Questions
The Topsky LT-CPF-60LY is priced on request. Contact us for current pricing and a tailored quote for your market.
The Topsky LT-CPF-60LY is a mechanised shotcrete (sprayed concrete) spraying robot designed for ground support and surface lining operations in underground mine roadways and tunnels. It combines a mobile tracked platform with an articulating spraying arm to enable efficient, single-operator concrete spraying in confined underground environments.
The platform features a compact footprint with a small turning radius for manoeuvrability in narrow headings, an articulating arm with a wide spraying range, and a design that keeps the operator more than 1 metre from the active spray surface. It is rated for single-operator use, reducing the personnel required on shift while maintaining consistent application quality.
The LT-CPF-60LY targets underground mining, tunnel construction, and subsurface infrastructure projects where mechanised shotcrete placement is used for ground support, surface stabilisation, and lining of newly excavated openings. It is specifically positioned for environments where manual access is constrained or where reducing operator exposure to spray zone hazards is a priority.
Yes, Robotix Market ships worldwide to qualified buyers. The LT-CPF-60LY is covered by the manufacturer's warranty as provided by Topsky; no installation or on-site service is included with purchase. Contact us for shipping logistics and lead time details for your region.
Submit a quote request through the Robotix Market website or contact our team directly. Due to the specialised industrial nature of this equipment, pricing and availability are confirmed per order. Our team can assist with product specifications, regional shipping arrangements, and documentation requirements.
